Specifications
| Material | Valve: Brass<br>Actuator: Die-cast aluminum |
| Seal Material | PTFE<br>Material in contact with Fluid: Brass, Zinc plated Steel, Stainless Steel, PTFE, Viton (FKM) |
| Media | No. 2 Fuel Oil at 60 SSU, No. 4 Fuel Oil at 300 SSU<br>No. 5 Fuel Oil at 5000 SSU, No. 6 Fuel Oil at 5000 SSU (Heated)<br>B20/100 Biodiesel Fuel Oil |
| Pipe Sizes | 3/4" by default; can be reduced to 1/2" on-site by installating pipe reducers (not supplied) |
| Function | 3-Ways by default; can be changed to 2-Ways by installing a plug on port 3 (not supplied) |
| Flow Factor CV (Kv) | 5.16 (4.46)<br>5.47 (4.73) |
| Maximum Operating Pressure Differential bar (psi) | 300 (20.68) |
| Maximum Fluid Temperature °F (°C) | 300 (149) |
| Ambient Temperature Range | -40°F to +150°F <br>(-40°C to +66°C) |
| Valve Actuation | Motorized |
| Voltage | 120V/60Hz, 110V/50Hz, 240V/60Hz, 230V/50Hz |
