ASCO™ 384 3-Way Solenoid Pinch Valve

The ASCO Series 384 is a 3-way solenoid pinch valve designed for use with highly aggressive or high-purity liquids. The 3-way valve features hermetic separation of its control mechanism and the fluid within the tubing to prevent particulate contamination caused by friction of moving parts. This construction assures maximum purity of liquids in analytical and medical instrumentation and industrial applications. Typical applications include hemodialysis, urinary collection systems, intravenous (IV) systems, and drug dispensing.

Specifications

Valve ActuationSolenoid
Body MaterialAluminum
MediaAggressive Liquids/Gases
Pipe / Port Size3 way - 3/2 Universal ; 3/2 Normally Closed
Port Type12 DC, 24 DC | 50/60
Function3 way - &frac32; Universal, &frac32; Normally Closed
FlowCorrosive, Indoor
Voltage12 DC;24 DC | 50/60
Max Differential / Max Operating PressureVacuum to 150 PSIG
Operating EnvironmentCorrosive, Indoor
Standards / Regulations
