Specifications
| Pressure Rating | Maximum Inlet Pressure: 3600 psig / 248 bar <br>Outlet Pressure Ranges:<br>50-89 psig / 3.4-6.1 bar<br>90-200 psig / 6.2-13.8 bar<br>201-320 psig / 13.9-22.1 bar |
| Material | Body: Aluminum 6061-T6 with Nickel Plating <br>Seat: Vespel®<br>Main Valve: 17-4 Stainless Steel<br>Sensor: Aluminum 6061-T6<br>Sensor Insert: 17-4 Stainless Steel<br>Remaining Parts: 300 Series Stainless Steel, Teflon®, Buna-N, Ethylene Propylen |
| Operating Temperature | -40°F to 200°F / -40°C to 93°C |
| Port Size & Type | Inlet & Outlet Port Type: SAE, NPTF <br>Inlet & Outlet Port Size: 1/4 Inlet, 3/8 Outlet |
| Flow Capacity | Cv = 0.5 |
| Load Type | Spring |
| Weight | 1.4 lbs / 0.6 kg |
| Additional Information | For custom modifications or a complete system solution, please contact your local sales office. |
