Specifications
| Pressure Rating | Maximum Inlet Pressure: 5100 psig / 351 bar (Aluminum body) - 10,200 psig / 702 bar (Stainless steel body)<br>Maximum Outlet Pressure: 450 psig / 31.0 bar |
| Body Material | Aluminum 6061-T6 with Electroless Nickel Plating, 316 Stainless Steel |
| Seat Material | Vespel® |
| O-Rings | Buna-N |
| Main Valve Material | 316 Stainless Steel |
| Sensor Material | Aluminum 6061-T6 |
| 10 Micron Filter | 316 Stainless Steel |
| Remaining Parts | 300 Series Stainless Steel, Teflon®, 18-8 Stainless Steel |
| Operating Temperature | -30°F to 165°F / -34°C to 74°C |
| Port Size & Type | Inlet & Outlet Port Type: SAE, NPTF <br>Inlet & Outlet Port Size<br>1/4 Inlet, 1/4 Outlet, 1/4 Gauge <br>3/8 Inlet, 1/2 Outlet, 3/8 Gauge<br>3/8 Inlet, 3/8 Outlet, 1/4 Gauge |
| Flow Capacity | Cv = 0.50 |
| Weight (approximate) | 1.4 lbs / 0.6 kg |
| Additional Information | For custom modifications or a complete system solution, please contact your local sales office. |
