Specifications
| Pressure Rating | Maximum Inlet Pressure: 150 or 250 psig / 10.3 or 17.2 bar <br>Outlet Pressure Ranges: 0-30, 0-60, 0-100 psig / 0-2.1, 0-4.1, 0-6.9 bar |
| Material | Body: 316L VAR Stainless Steel with Electropolish<br>Valve Seat: Teflon® or PCTFE<br>Diaphragm & Stem: 316L Stainless Steel<br>Seal & Remaining Parts: 316 Stainless Steel<br> |
| Operating Temperature | Teflon® Seat: -40°F to 160°F / -40°C to 71°C<br>PCTFE Seat: -40°F to 140°F / -40°C to 60°C<br> |
| Port Size & Type | Inlet & Outlet Port: 1/4 MVCR, fixed, 1/2 FVCR, 1/2 MVCR, 1/2 Tube, 3/4 Tube <br>Gauge Ports: 1/4 HPIC, 1/4 FVCR, 1/4 MVCR, fixed, 1/4 MVCR, swivel<br> |
| Flow Capacity | Cv = 1.8 |
| Weight | 3.2 lbs / 1.5 kg |
| Additional Information | For custom modifications or a complete system solution, please contact your local sales office. |
