Specifications
| Maximum Inlet Pressure | Stainless Steel: 10,000 psig / 690 bar<br>Brass: 6000 psig / 415 bar <br> |
| Outlet Pressure Ranges | 5-500, 5-800, 10-1500, 15-2500, 25-4000, 50-6000, 200-10,000 psig<br>0.3-35, 0.3-55, 0.7-105, 1-175, 1.7-275, 3.4-415, 14-690 bar<br> |
| Body Material | 316 Stainless Steel or Brass |
| Seat Material | Main Valve Seat: Vespel®<br>Vent Valve Seat: CTFE<br> |
| Bonnet | 300 Series Stainless Steel |
| Back-up Rings | Teflon® |
| 40 Micron Filter | 300 Series Stainless Steel or Bronze |
| Trim | 300 Series Stainless Steel |
| Port Size & Type | Inlet & Outlet Port Type: SAE, NPTF, MS33649, High Pressure, Medium Pressure<br>Inlet & Outlet Port Size: 1/4, 3/8 (NPTF only)<br> |
| Operating Temperature | -40°F to 165°F / -40°C to 74°C |
| Flow Capacity | Standard: Cv = 0.06<br>Optional: Cv = 0.02, 0.12, 0.30<br> |
| Load Type | Air Ratio, Dome, Bias, Wrench Adjust |
| Weight (without gauges) | Stainless Steel: 5.5 lbs / 2.5 kg <br>Brass: 5.7 lbs / 2.6 kg<br> |
| Additional Information | For custom modifications or a complete system solution, please contact your local sales office. |
