Specifications
| Maximum Inlet Pressure | 10,000 psig / 689 bar |
| Outlet Pressure Ranges | 5-500, 5-800, 10-1500,15-2500, 25-4000, 50-6000, and 200-10,000 psig<br>0.35-34.5, 0.35-55.2, 0.69-103, 1.03-172, 1.72-276, 3.45-414,and 13.8-689 bar<br> |
| Body Material | 316 Stainless Steel |
| Seat Material | CTFE (26-17X1 through 26-17X4), Teflon® (26-17X5 through 26-17X7) |
| O-Rings | Buna-N |
| Back-up Rings | Teflon® |
| Seal | CTFE |
| Trim | 300 Series Stainless Steel |
| Port Size & Type | 1/8, 1/4, 3/8, 1/2<br> SAE, NPTF, MS33649, High Pressure, Medium Pressure<br>1/2, 1<br>Flange |
| Operating Temperature | -40°F to 165°F / -40°C to 74°C |
| Flow Capacity | Cv = 0.10 (26-17X1 through 26-17X4) <br>Cv = 0.14 (26-17X5 through 26-17X7)<br> |
| Weight | 5 lbs / 2.2 kg |
| Additional Information | For custom modifications or a complete system solution, please contact your local sales office. |
