Specifications
| Pressure Rating | Maximum Inlet Pressure: 3500 psig / 241 bar <br>Outlet Pressure Ranges: 0-25, 0-50, 0-100, 0-150, 0-250 psig / 0-1.7, 0-3.4, 0-6.9, 0-10.3, 0-17.2 bar |
| Material | Body: 316 Stainless Steel, Brass or Monel <br>Bonnets: 300 Series Stainless Steel or Brass<br>Diaphragms: 316 Stainless Steel or Elgiloy®<br>Seats and Friction Sleeve (inner): Teflon® |
| Remaining Parts | 316 Stainless Steel and Brass (for Brass models) |
| Operating Temperature | -40°F to 165°F / -40°C to 74°C |
| Port Size & Type | 1/4 NPTF |
| Flow Capacity | Cv = 0.05 |
| Weight (without gauges) | 3 lbs / 1.4 kg |
| Additional Information | For custom modifications or a complete system solution, please contact your local sales office. |
