Specifications
| Pressure Rating | Maximum Inlet Pressure: 500 psig / 34.5 bar<br>Outlet Pressure Ranges: 0-20, 0-50, 0-100, 0-150, 0-250 psig / 0-1.4, 0-3.4, 0-6.9, 0-10.3, 0-17.2 bar |
| Material | Body, Bonnet, Back-cap: 316 Stainless Steel or Brass<br>Diaphragm: Ethylene Propylene, Nylon Reinforced, Gylon® (PTFE)<br>Vent: CTFE, Vespel® |
| Main Valve, O-Rings | Buna-N, Ethylene Propylene , Chemraz®, Viton® |
| Remaining Parts | 300 Series Stainless Steel, Nitronic 60 |
| Ambient Operating Temperature | -4°F to 165°F / -20°C to 74°C |
| Port Size & Type | 1/4, 1/2, 3/4, 1<br>NPTF, HPIC<br>1<br>Flange |
| Flow Capacity | Cv = 5.0 |
| Load Type | Spring, Dome, Air (optional) |
| Weight | Stainless Steel: 15 lbs / 6.8 kg <br>Brass: 16 lbs / 7.3 kg |
| Additional Information | For custom modifications or a complete system solution, please contact your local sales office. |
