Specifications
| Maximum Inlet Pressure | 3000 psig / 207 bar |
| Outlet Pressure Ranges | 0-30, 0-60, 0-100, 0-150, 0-200, 0-300, 0-500, 0-750, 0-1000 and 0-1500 psig / 0-2.1,0-4.1, 0-6.9, 0-10.3, 0-13.8, 0-20.7, 0-34.5, 0-51.7, 0-68.9 and 0-103 bar |
| Body Material | Brass, 316 Stainless Steel |
| Seat Material | Teflon® (Regulators), CTFE (Valves) |
| Diaphragm | (Outlet Option 0-5): 316 Stainless Steel |
| O-Rings | (Outlet Option 6-9): Buna-N |
| Friction Sleeve | Inner: Teflon®<br>Outer: 316 Stainless Steel |
| Remaining Parts | Brass, 316 Stainless Steel |
| Operating Temperature | -40°F to 165°F / -40°C to 74°C |
| Flow Capacity | Cv = 0.06 |
| Weight (approximate) | 10 lbs / 4.5 kg |
| Additional Information | For custom modifications or a complete system solution, please contact your local sales office. |
