Specifications
| Pressure Rating | Maximum Inlet Pressure: 300 psig / 20.7 bar <br>Outlet Pressure Ranges<br>0-20, 0-50, 0-100, 0-150, 0-250 psig / 0-1.4, 0-3.4, 0-6.9, 0-10.3, 0-17.2 bar |
| Material | Body: 316L Stainless Steel <br>Diaphragm: Gylon®<br>Seat, Valve: Ethylene Propylene<br>O-Rings: Ethylene Propylene<br>Valve Spring: Elgiloy®<br>Remaining Parts: 316 Stainless Steel |
| Operating Temperature | -20°F to 300°F / -28°C to 148°C |
| Port Size & Type | 1/2, 3/4, 1, 1-1/2<br>Sanitary, Tube<br>1/4 HPIC<br><br>1/2 Port size limits regulator to Cv = 2.5<br>3/4 Port size limits regulator to Cv = 3.5 |
| Flow Capacity | 1/2 Port Size: Cv = 2.5 <br>3/4 Port Size: Cv = 3.5<br>1 & 1-1/2 Port Size: Cv = 5.0 |
| Load Type | Spring, Dome |
| Weight | 16 lbs / 7 kg |
| Additional Information | For custom modifications or a complete system solution, please contact your local sales office. |
