Specifications
| Pressure Rating | Maximum Inlet Pressure: 300 psig / 20.7 bar <br>Outlet Pressure Ranges: 0 -<br>20, 50, 100, 150, 250 and 300 (Dome load only) psig<br>1.4, 3.4, 6.9, 10.3, 17.2 and 20.7 (Dome load only) bar |
| Material | Body: 316L Stainless Steel <br>Diaphragm: Gylon®<br>Seat, Valve: Ethylene Propylene<br>O-Rings: Ethylene Propylene<br>Valve Spring: Elgiloy®<br>Remaining Parts: 316 Stainless Steel |
| Operating Temperature | -20°F to 300°F / -28°C to 148°C |
| Port Size & Type | 3/4 Sanitary<sup>1</sup><br>1, 1-1/2 Sanitary<br>3/4 Tube<sup>1</sup><br>1, 1-1/2 Tube<br>1/4 HPIC<br><sup>1</sup> Port size limits regulator to Cv = 6.5 |
| Flow Capacity | Cv = 10.0 |
| Load Type | Spring, Dome |
| Weight (approximately) | 35 lbs / 15.9 kg |
| Additional Information | For custom modifications or a complete system solution, please contact your local sales office. |
