Specifications
| Maximum Inlet Pressure | 150 psig / 10.3 bar |
| Outlet Pressure Ranges | Spring (handknob): 0 -<br>10, 25, 50, 100, 150 psig / 0.69, 1.7, 3.4, 6.9, 10.3 bar<br>Spring Bias and Dome: 0-100 psi / 0-6.9 bar (See Part Number Selector for more details) |
| Material | Body: 316L Stainless Steel <br>Seat: Teflon®, PEEK-OPTIMA® or PEEK-Classix®<br>Valve Guide, Diaphragm: 316 Stainless Steel<br>Seat Retainer: Nitronic 60 |
| Friction Sleeve | Inner: Teflon®<br>Outer: 316 Stainless Steel |
| Remaining Parts | 316 Stainless Steel |
| Operating Temperature (media only) | Teflon® Seat: -40°F to 165°F / -40°C to 74°C<br>PEEK-OPTIMA® or Peek-Classix® Seat: -40°F to 400°F / -40°C to 204°C |
| Port Size & Type | Inlet & Outlet Port Type: Sanitary, Tube <br>Inlet & Outlet Port Size: 3/8 (Tube Only), 1/2 |
| Flow Capacity | Cv = 0.02, 0.06, 0.15, 0.24 |
| Load Type | Spring, Spring Bias, Dome |
| Weight (approximately) | 2.0 lbs / 0.9 kg |
| Additional Information | For custom modifications or a complete system solution, please contact your local sales office. |
