Specifications
| Maximum Inlet Pressure | Air, O2: 160 to 2900 psig / 11 to 200 bar<br>N2O, CO2: 160 to 870 psig / 11 to 60 bar |
| Outlet Pressure | Air: 73 psig / 5 bar at nominal flow 80 l/min<br>O2: 73 psig / 5 bar at nominal flow 76 l/min<br>N2O: 73 psig / 5 bar at nominal flow 65 l/min<br>CO2: 73 psig / 5 bar at nominal flow 65 l/min<br>Xe: 73 psig / 5 bar at nominal flow 37 l/min |
| Fluid Media | Medical O2, Air, N2O, CO2, Xe |
| Relief Valve | Opening pressure: 116 psig / 8 bar<br>Minimum flow: 220 l/min (Air) |
| Temperature Range | Operation: -4°F to 140°F / -20°C to 60°C <br>Storage: -40°F to 158°F / -40°C to 70°C |
| Weight | approximately 2.65 lbs / 1.2 kg (depending on Inlet connection) |
| Additional Information | For custom modifications or a complete system solution, please contact your local sales office. |
