Specifications
| Valve Actuation | Solenoid - Air Pilot |
| Pipe / Port Size | 1/4, 3/8, 8 mm, 6 mm |
| Port Type | NPTF, G ISO228/1-G BSPP, Push-in |
| Function | 4 way - 5/2, 4 way - 5/3 - Closed Center, 4 way - 5/3 - Open Center, 4 way - 5/3, 4 way - 5/3 - Pressure Center, Dual 3 - Way 2 X Normally Closed, Dual 3 - Way 2 X Normally Open |
| Flow | From 1.0 Cv to 2.0 Cv<br>From .86 to 1.73 Kv<br>From 1000 To 2000 L/M<br>From 60 to 120 M3/H<br>From 35.3 To 70.6 SCFM |
| Max Differential / Max Operating Pressure | Vacuum to 150 PSIG, Vacuum to 10.3 Bar |
| Standards / Regulations | Machine Safety 13849 (ISO 13849-1 and ISO 13849-2) |
| Operating Environment | Indoor |
| Media | Air, Inert Gas |
