Specifications
| Indirect mounting for series | PRA, PRE, CCI, KPZ, KHZ, FLT, GPC, CVI |
| Version | to mount on cylinder PRA, CCI, KPZ, KHZ, GPC, CVI, welding-proof |
| Switch descr. | PNP |
| Min. operating voltage DC | 10 V DC |
| Max. operating voltage DC | 30 V DC |
| Nominal current, actuated state | ≤ 10 mA |
| Quiescent current (without load) | ≤ 5 mA |
| Protection class | IP67, IP65 |
| Min. ambient temperature | -25 °C |
| Max. ambient temperature | 70 °C |
| Voltage drop U at Imax | ≤ 1,8 V |
| Max. DC switching current | 0.2 A |
| Max. switching frequency | 20 Hz |
| Switching point precision | ±0,1 mT |
| LED status display | Yellow |
| Electrical connection 2, type | Plug |
| Electrical connection 2, thread size | M12 |
| Electrical connection 2, number of poles | 3-pin |
| Short circuit resistance | short circuit resistant, Protected against polarity reversal |
| Shock resistance | 30 g / 11 ms |
| Vibration resistance | 55 Hz, 1 mm |
| Housing material | Polyamide |
