AVENTICS™ 3/2-directional valve, Series 490, Min. working pressure 4 bar 5724970220

Part Number:

AVENTICS-5724970220

Where to Buy
View CAD
View Datasheet
V490-3/2NC-024DC-ND0,8

Specifications

ActivationElectrically
Frame size490
Valve typePoppet valve
Switching principle3/2, with spring return
Sealing principleSoft seal
Compressed air connection typePush-in fitting
Compressed air connection outputØ 4
Min. working pressure4 bar
Max. working pressure7 bar
Electrical connection typePlug
Electrical connection sizeISO 15217, form C
Protection class with connectionIP65
Operational voltage24 V DC
Voltage tolerance DC-20 % / +20 %
PilotInternal
Coil width20 mm
Power consumption DC2 W
Duty cycle100 %
Typ. switch-on time16 ms
IndustryIndustrial, Polyoxymethylene
Weight0.079 kg
Min. ambient temperature-15 °C
Max. ambient temperature50 °C
