AVENTICS™ 3/2-shut-off valve, mechanically operated, Series AS2-BAV R412006257

Part Number:

AVENTICS-R412006257

$130.17

Qty:
ADD TO CART
View Datasheet
AS2-SOV-G038-MAN-4-ST

Specifications

ActivationMechanical
Nominal flow Qn2000 l/min
Compressed air connectionG 3/8
Min. working pressure0 bar
Max. working pressure16 bar
Actuating elementrotary switch
Sealing principleSoft seal
TypePoppet valve
PartsShut-off valve
Lock typelockable
Lock typefor padlocks
Can be assembled into blocksCan be assembled into blocks
Min. ambient temperature-10 °C
Max. ambient temperature50 °C
MediumCompressed air, Neutral gases
Max. particle size25 µm
Compressed air connection, exhaustG 1/4
Nominal flow Qn 1 to 22000 l/min
Nominal flow Qn 2 to 3380 l/min
Weight0.206 kg
Housing materialPolyamide
Seal materialAcrylonitrile butadiene rubber
Material locking baseGalvanized Steel
Material, front coverAcrylonitrile butadiene styrene
Material threaded bushingDie cast zinc
