AVENTICS™ ED07 series proportional pressure regulator, EtherCAT R414014311

Part Number:

AVENTICS-R414014311

View Datasheet
ED07-000-100-ECAT-4M12X-EXT-420

Specifications

ProtocolEtherCAT
ControlDirectly controlled
ControlEtherCAT
Operational voltage DC24 V
Max. current consumption1400 mA
Actual output value4 ... 20 mA
Nominal input value4 ... 20 mA
Min. regulation range0 bar
Max. regulation range10 bar
Min. working pressure0.5 bar
Max. working pressure12 bar
Hysteresis< 0,03 bar
MediumCompressed air
Nominal flow Qn1300 l/min
Min. ambient temperature5 °C
Max. ambient temperature50 °C
Protection classIP65
TypePoppet valve
CertificatesCE declaration of conformity
Signal connectionM12
