Specifications
| Pressure Rating | Maximum Inlet Pressure and Maximum Outlet Pressure: See Part Number Selector |
| Material | Body: 316 Stainless Steel or Brass <br>Seat, Vent, Main Valve, O-Ring: See Part Number Selector<br>Back-up Ring: Teflon® |
| Filter | 26-201XX-XX: Bronze<br> 26-202XX-XX: 300 Series Stainless Steel |
| Remaining Parts | 316 Stainless Steel and 17-4 Stainless Steel |
| Operating Temperature | -15°F to 165°F / -26°C to 73°C |
| Port Size & Type | 1/4, 3/8, 1/2<br>SAE, NPTF, MS33649, High Pressure/Aminco, Medium Pressure/Slimline <br>Vent Port: 1/4 SAE, 1/4 NPTF, 1/4 MS33649 |
| Flow Capacity | Cv = 0.02, 0.06, 0.12, or 0.30 |
| Load Type | Spring, Dome, Air |
| Weight (approximately) | 5.5 lbs / 2.5 kg |
| Additional Information | For custom modifications or a complete system solution, please contact your local sales office. |
