Specifications
| Controlled Pressure Ranges | 0-20, 0-50, 0-125, 0-200 psig<br>0-1.4, 0-3.4, 0-8.6, 0-13.8 bar<br>0-300 psig / 0-20.7 bar for Air load |
| Body, Bonnet, Back-cap | 316 Stainless Steel or Brass |
| Main Valve Seat | Buna-N, Ethylene Propylene, Chemraz® or Viton® |
| Diaphragm | Gylon® and Viton® |
| O-Rings | Buna-N, Ethylene Propylene, Chemraz® or Viton® |
| Operating Temperature | -20°F to 165°F / -29°C to 74°C |
| Port Size & Type | Inlet & Outlet Port Type: SAE, NPTF, MS33649<br>Inlet & Outlet Port Size: 1/2, 3/4, 1<br> |
| Flow Capacity | Cv = 5.0 |
| Load Type | Spring, Air, Dome |
| Weight | Stainless Steel: 15 lbs / 6.8 kg <br>Brass: 16 lbs / 7.3 kg |
| Additional Information | For custom modifications or a complete system solution, please contact your local sales office. |
