Specifications
| Maximum Inlet Pressure | Stainless Steel: 10,000 psig / 690 bar<br>Brass: 6000 psig / 414 bar |
| Outlet Pressure Ranges | 0-500, 0-800, 10-1500, 15-2500, 25-4000, 50-6000 psig<br>0-34.5, 0-55.2, 0.69-103, 1.0-172, 1.7-276, 3.4-414 bar |
| Material | Body: Brass, 303, or 316 Stainless Steel<br>Main Valve Seat: Vespel®<br>Vent Valve Seat: CTFE<br>O-Rings: Buna-N<br>Back-up Rings: Teflon® |
| Remaining Parts | 300 Series Stainless Steel |
| Filter Material | Brass Body: 40 micron (nominal) - Bronze<br> Stainless Steel Body: 15 micron (nominal) - 316 Stainless Steel |
| Operating Temperature | -40°F to 165°F / -40°C to 75°C |
| Port Size & Type | 1/4 NPTF |
| Flow Capacity | Cv = 0.06 |
| Load Type | Spring |
| Weight | 4.8 lbs / 2.2 kg |
| Additional Information | For custom modifications or a complete system solution, please contact your local sales office. |
