Specifications
| Maximum Inlet Pressure | 6000 psig / 414 bar |
| Outlet Pressure Ranges | Spring Load: 0-200, 0-400 psig / 0-14, 0-28 bar<br> Air/Dome Load: 0-600 psig / 0-41 bar |
| Material | Body: 316 Stainless Steel or Brass <br>40 Micron Filter: Bronze<br>Main and Vent Valve Seats: Vespel® SP21<br>Back-up Rings: Teflon® |
| O-Ring | Buna-N, Viton®, Kalrez®, Ethylene Propylene |
| Remaining Parts | 300 Series Stainless Steel, Brass, Monel |
| Ambient Operating Temperature | -15°F to 165°F / -26°C to 74°C |
| Port Size & Type | Inlet & Outlet Port Size: 3/8, 1/2 <br>Inlet & Outlet Port Type: SAE, NPTF, MS33649<br>Vent Port: 1/4 SAE, 1/4 NPTF, 1/4 MS33649 |
| Flow Capacity | Cv = 0.3 |
| Load Type | Air, Dome, Spring |
| Weight | 4.75 lbs / 2.2 kg |
| Additional Information |
