Specifications
| Maximum Inlet Pressure | 800 psig / 55.2 bar |
| Controlled Pressure Ranges | 40-150, 40-300, 100-700, 100-800 psig<br>2.8-10.3, 2.8-20.7, 6.9-48.3, 6.9-55.2 bar<br> |
| Material | Body: 316 Stainless Steel or Brass<br>Seat: CTFE<br>O-Ring: Viton®<br>Back-up Ring: Teflon®® |
| Remaining Parts | Stainless model: 316 Stainless Steel<br>Brass model: Brass and 300 Series Stainless Steel |
| Operating Temperature | -15°F to 140°F / -26°C to 60°C |
| Port Size & Type | 1/4 NPTF |
| Flow Capacity | Cv = 0.10 |
| Weight | 2 lbs / 0.9 kg |
| Additional Information | For custom modifications or a complete system solution, please contact your local sales office. |
