Specifications
| Maximum Inlet Pressure | Air Loaded: 500 psig / 34.5 bar<br>Dome Loaded: 5500 psig / 379 bar<br>Spring Loaded: 500 psig / 34.5 bar<br> |
| Material | Body: 303 and 316 Stainless Steel<br>Seat: Glass Filled Peek, Vespel® SP1<br>O-Rings: Buna-N, Viton®, Ethylene <br>Propylene<br>Back-up Rings: Teflon®<br> |
| Remaining Parts | 303 Stainless Steel |
| Operating Temperature | -40°F to 165°F / -40°C to 74°C |
| Port Size & Type | 1<br>SAE, NPTF, MS33649 |
| Flow Capacity | Cv = 5.0 |
| Load Type | Air, Dome, Spring |
| Weight | 30 lbs / 13.6 kg |
| Additional Information | For custom modifications or a complete system solution, please contact your local sales office. |
