Specifications
| Pressure Rating | Maximum Inlet Pressure: 15,000 psig / 1034 bar<br>Maximum Outlet Pressure: 200-15,000 psig / 13.8-1034 bar<br>(non-adjustable spring bias pressure: 175-200 psig / 12-13.8 bar) |
| Material | Body: 17-4 Stainless Steel <br>Seat, Main Valve: Vespel® SP1<br>O-Ring: Buna-N<br>Back-up Ring: CTFE<br>Remaining Parts: 300 Series Stainless Steel, 17-4 Stainless Steel and Nitronic 60 |
| Operating Temperature | -15°F to 165°F / -26°C to 74°C <br><sup>2</sup> For extended temperatures from -40°F to 400°F / -40°C to 204°C, consult TESCOM. |
| Port Size & Type | Inlet & Outlet Port Type: Medium Pressure<br>Inlet & Outlet Port Size: 9/16 |
| Flow Capacity | Cv = 0.06 |
| Weight (approximate) | 13 lbs / 5.9 kg |
| Additional Information | For custom modifications or a complete system solution, please contact your local sales office. |
