Specifications
| Pressure Rating | Maximum Inlet Pressure: 600 or 3500 psig / 41.4 or 241 bar <br>Outlet Pressure Ranges: 0-30, 0-60, 0-100, 0-150 and 250 psig / 0-2.1, 0-4.1, 0-6.9, 0-10.3 and 17.2 bar |
| Material | Body: 316L Stainless Steel Electropolish or 316L VAR Stainless Steel Electropolish <br>Diaphragm: 316L Stainless Steel or Hastelloy®<br>Spring: 316 Stainless Steel or Elgiloy® |
| Seat | PCTFE or Teflon® (Vespel® optional for 3500 psig / 241 bar model only) |
| Stem, Seat Retainer, Valve Guide | 316 Stainless Steel or Hastelloy® |
| Operating Temperature | PTCFE Seat: -40°F to 140°F / -40°C to 60°C<br>Teflon® Seat: -40°F to 160°F / -40°C to 71°C<br>Vespel® Seat: -40°F to 350°F / -40°C to 177°C |
| Port Size & Type | 1/4 H.P.I.C. <br>1/4, 1/2<br>Male Swivel, Female Swivel<br>1/4 Tube Stubs |
| Flow Capacity | Cv = 0.06 (3500 psig / 241 bar model)<br>Cv = 0.15 (600 psig / 41.4 bar model) |
| Weight (without gauges) | 2.0 lbs / 0.9 kg |
| Additional Information | For custom modifications or a complete system solution, please contact your local sales office. |
