Specifications
| Pressure Rating | Maximum Inlet Pressure: 600 psig / 41.4 bar<br>Outlet Pressure Ranges: 30, 60, 100, 150 psig / 2.1, 4.1, 6.9, 10.3 bar |
| Body Material | 316L Stainless Steel Electropolish or 316L VAR Stainless Steel Electropolish |
| Diaphragm | Hastelloy® |
| Valve Seat | PCTFE or Teflon® PFA |
| Seat Retainer | Nitronic 60 Stainless Steel |
| Stem, Seal & Remaining Parts | 316 Stainless Steel |
| Operating Temperature | Teflon® PFA Seat: -40°F to 160°F / -40°C to 71°C<br>PCTFE Seat: -40°F to 140°F / -40°C to 60°C<br> |
| Port Size & Type | 3/8 Tube Stubs<br>1/2 Tube Stubs<br>1/2 Male Swivel<br>1/2 Female Swivel<br>3/8 Compression Fitting<br>1/2 Compression Fitting |
| Flow Capacity | Cv = 1.0 |
| Load Type | Hand |
| Weight (without gauges) | 3.5 lbs / 1.6 kg |
| Additional Information | For custom modifications or a complete system solution, please contact your local sales office. |
