Specifications
| Pressure Rating | Maximum Inlet Pressure: 3000 psig / 207 bar <br>Maximum Outlet Pressure Range: 0-500 psig / 0-34.5 bar |
| Body Material | 316 Stainless Steel, Brass |
| Seat & Seal | CTFE, Teflon® |
| O-Rings | Buna-N, Viton® |
| Retainer, Seat | Nitronic 60 or Brass |
| Spring & Diaphragm | 316 Stainless Steel |
| Remaining Parts | 316 Stainless Steel, Brass |
| Operating Temperature | -15°F to 140°F / -26°C to 60°C<br>*For extended temperatures from -40° to 400°F / -40°C to 177°C, consult TESCOM |
| Port Size & Type | 1/2 NPTF |
| Flow Capacity | Cv = 1.0 |
| Load Type | Dome |
| Weight | 3.5 lbs / 1.6 kg |
| Additional Information | For custom modifications or a complete system solution, please contact your local sales office. |
