TESCOM™ CR441800 Series Changeover Pressure Regulator

Contact Sales
CR441800Series is a compact, high pressure changeover system which combines the changeover regulator and a line regulator into a compact wall mount system for general purpose and industrial gases. It provides continuous low flow of gas from two high pressure sources. Ideal for use in analyzer carrier gas and laser resonator gas applications.

Specifications

Maximum Inlet Pressure3500 or 6000 psig / 241 or 414 bar
Maximum Delivery PressureSeven maximum delivery pressures from 500 to 2000 psig / 34.5 to 138 bar
MaterialsBody: Brass, 316 Stainless Steel, or Nickel-plated Brass <br>Bonnet: 300 Series Stainless Steel, Brass, or Nickel-plated Brass<br>Valve Seat: Vespel®<br>O-Ring: FKM<br>
Remaining PartsBrass and 300 Series Stainless Steel
Operating Temperature-15°F to 165°F / -26°C to 74°C
Port Size & Type1/4 NPTF
Flow CapacityCv = 0.06
Weight3 lbs / 1.4 kg
Additional InformationFor custom modifications or a complete system solution, please contact your local sales office.
