Specifications
| Pressure Rating | Maximum Inlet Pressure: 290 psig / 20.0 bar <br>Outlet Pressure Ranges<br>0.07-0.73, 0.73-7.25, 2.9-22, 14.5-58 psig<br>5-50, 50-500 mbar, 0.20-1.5, 1.00-4.0 bar<br> |
| Material | Body: Aluminum <br>Diaphragm: Butyl Rubber with PTFE coating<br>Seat: NBR<br> |
| Port Size & Type | Inlet <br>Adapter: M16 x 1.5<br>Body: G 3/4 <br>Outlet: G 1 1/4<br>Gauge: G 1/2<br>Relief valve: L12, DIN 3853 (M18x1.5 + cone)<br> |
| Operating Temperature | -4°F to 158°F / -20°C to 70°C |
| Fluid Media | Non corrosive gases up to gas purity 5.0 (99.999 Vol %) |
| Nominal Flow Rate | Max. 72 (m3/h air) |
| Weight | 9.3 lbs / 4.2 kg |
| Additional Information | For custom modifications or a complete system solution, please contact your local sales office. |
