Specifications
| Maximum Inlet Pressure | Cv = 0.06: 4500 psig / 310 bar<br>Cv = 0.2: 3000 psig / 207 bar<br> |
| Outlet Pressure Ranges | 15, 25, 50, 125, 250 psig<br>103, 172, 345, 862, 1724 kPa<br>1.0, 1.7, 3.4, 8.6, 17.2 bar<br> |
| Body Material | 316L Stainless Steel, Nickel-Plated Brass |
| Seat Material | PCTFE, Polyimide*<br>*Per ASTM D 6456-99 Type II Class 1M (Meldin® 7021 or Vespel® SP-21)<br> |
| Seal | Teflon® or Buna-N |
| Diaphragm | 316 Stainless Steel or Neoprene |
| Filter | 10 micron nominal sintered Bronze<br>10 micron nominal sintered 316 Stainless Steel |
| Remaining Parts | Brass, 300 Series Stainless Steel |
| Port Size & Type | Inlet & Outlet: 1/4 NPTF<br>Accessories: 1/4 NPTF |
| Operating Temperature | PCTFE Seat: -40°F to 140°F / -40°C to 60°C<br>Polyimide* Seat: -40°F to 250°F / -40°C to 121°C<br> |
| Flow Capacity | Cv = 0.06, 0.2 |
| Load Type | Spring only |
| Weight | 2.4 lbs / 1.1 kg |
| Additional Information | For custom modifications or a complete system solution, please contact your local sales office. |
