Specifications
| Pressure Rating | Maximum Inlet Pressure: 4500 psig / 310 bar<br>Maximum Outlet Pressure: 15, 50, 125, 250 psig / 103, 345, 862, 1724 kPa / 1.0, 3.4, 8.6, 17.2 bar |
| Material | Body: 316L Stainless Steel, Nickel-Plated Brass<br>Seat: PCTFE<br>Diaphragm: 316 Stainless Steel or Neoprene<br>Seal: Teflon® or Buna-N |
| Filter | 10 micron nominal sintered Bronze or 316 Stainless Steel |
| Remaining Parts | Brass, 300 Series Stainless Steel |
| Operating Temperature | -40°F to 140°F / -40°C to 60°C |
| Connections | Inlet & Outlet: 1/2 NPTF<br>Accessories: 1/4 NPTF |
| Flow Capacity | Cv = 1.0 |
| Load Type | Spring only |
| Weight | 5.5 lbs / 2.5 kg |
| Additional Information | For custom modifications or a complete system solution, please contact your local sales office. |
