Specifications
| Maximum Operating Pressure | 3500, 6000, 10,000 psig / 241, 414, 690 bar |
| Body Material | Brass, 316 Stainless Steel |
| Seat Material | CTFE, PEEK, Tefzel® ETFE, Vespel® |
| O-Rings | Buna-N, Kalrez®, Viton®, Ethylene Propylene (E.P.), Urethane |
| Back-up Rings | Teflon®, CTFE |
| Valve Stem | 17-4 Stainless Steel |
| Remaining Parts | 316 Stainless Steel, Brass |
| VA Series Port Size & Type | 1/4 NPTF, 3/8 NPTF, 1/4 SAE, 1/8 NPTF (changes Cv to .5) |
| VG Series Port Size & Type | 3/8 NPTF, 1/2 NPTF, 3/4 NPTF, 3/8 SAE, 1/2 SAE |
| Flow Capacity | VA Series Valve: Cv = 0.75<br>VG Series Valve: CV = 2.0<br> |
| Weight (approximate) | VA Series Valve: 3 lbs / 1.4 kg <br>VG Series Valve: 5 lbs / 2.3 kg<br> |
| Additional Information | For custom modifications or a complete system solution, please contact your local sales office. |
