Part Number:
Specifications
| Body Material | Aluminum |
| Flow (Cv) | 0.1 |
| Valve Function | 4 way |
| Media | Air, Inert Gas |
| Pipe/Port Type & Size | NPT 1/4 |
| Valve Actuation | Solenoid - Direct Acting |
| Voltage & Frequency | 110 AC, 120 AC with 50/60 Hz |
| Product Weight | 1.50 lbs |
| Order Code | 1892 |
| Kit Number | 302753 |
| Coil Class | F |
| Coil Number | 064982-001-D |
| Min to Max Ambient Temperature | 32 - 125 °F |
| Min to Max Fluid Temperature | 32 - 104 °F |
| Orifice Size | 5/64 in |
| Watt Rating | 16.7 W |
| Mounting Brackets | OPTIONAL |
| Item Status | Active |
| Lead Length | 18 inch |
| Holding Current (VA) | 36 |
| Seating Elastomer | POLYETHYLENE |
| Mounting Direction | ANY |
