AVENTICS™ Check-choke valve, Series CC04 R412007401

Part Number:

AVENTICS-R412007401

$39.21

Qty:
ADD TO CART
Where to Buy
View CAD
View Datasheet
CC04-PA6-DA08-DA08-2_1_SLS

Specifications

Port 1Ø 8
Port 2Ø 8
Throttle bore Ø3.5 mm
direction of throttle2 > 1
Nominal flow Qn 2 to 1360 l/min
Compressed air connection type 1Push-in fitting
Compressed air connection type 2pin bushing
ThrottleExhaust Air Throttling
MediumCompressed air
Min. working pressure0.5 bar
Max. working pressure10 bar
Min. ambient temperature-10 °C
Max. ambient temperature70 °C
Min. medium temperature-10 °C
Max. medium temperature70 °C
Housing materialPolyamide
Seal materialAcrylonitrile butadiene rubber
Material flow control screwBrass
