Part Number:
Specifications
| Type | Adapters & contact bridges |
| Connector standard | EN 175301-803, form C, unshielded |
| with LED | Yellow |
| Min. ambient temperature | -25 °C |
| Max. ambient temperature | 90 °C |
| Max. current | 1.5 A |
| Protection class | IP67 |
| Protective circuit | Varistor |
| Operational voltage | 24 V AC/DC |
| Electrical connection 1, type | Socket |
| Electrical connection 1, thread size | EN 175301-803, form C |
| Electrical connection 1, number of poles | 2+E |
| Cable exit | angled |
| Cable exit angle | 90° |
| Electrical connection 2, type | Plug |
| Electrical connection 2, thread size | M12x1 |
| Electrical connection 2, number of poles | 3-pin |
| Electrical connection 2, coding | A-coded |
| Cable exit | straight |
| Cable exit angle | 180° |
| Mounting screw tightening torque | 0.4 Nm |
| Housing material | Polyurethane |
| Seal material | Nitrile butadiene rubber |
