Specifications
| Slot width | 6 mm T-slot |
| Cable | with cable |
| Max. operating voltage DC | 8.2 V DC |
| Certificates | ATEX, CE declaration of conformity, cULus, RoHS, UL (Underwriters Laboratories) |
| ATEX class G | II 2G Ex ia IIC T4 Gb |
| ATEX class D | II 2D Ex ia IIIC T135°C Db |
| Protection class | IP67 |
| Min. ambient temperature | -25 °C |
| Max. ambient temperature | 80 °C |
| Max. switching frequency | 1000 Hz |
| Electrical connection 2, type | Plug |
| Electrical connection 2, thread size | M12x1 |
| Electrical connection 2, number of poles | 2-pin |
| Shock resistance | 30 g / 11 ms |
| Vibration resistance | 10 - 55 Hz, 1 mm |
| Cable length L | 0.3 m |
| Housing material | Polyamide, fiber-glass reinforced |
| Material cable sheath | Polyurethane |
| Material locking screw | Stainless Steel |
