Specifications
| Type | SA1-MA |
| Mounting thread | M27x2 |
| Stroke | 40 mm |
| Max. energy absorption/stroke | 390 Nm |
| Max. energy absorption/hour | 175500 Nm |
| Cushioning | adjustable |
| Medium | Oil |
| Min. ambient temperature | -20 °C |
| Max. ambient temperature | 80 °C |
| Effective mass me min. | 38 kg |
| Effective mass me max. | 18000 kg |
| Min. return spring force | 11 N |
| Max. return spring force | 20 N |
| Min. impact speed | 0.1 m/s |
| Max. impact speed | 6 m/s |
| Mounting | Lock nut |
| Weight | 0.29 kg |
| Material cylinder tube | Steel, chrome-plated |
| Material piston rod | Stainless Steel |
| Material stop | Steel, chrome-plated |
| Material lock nut | Steel, chrome-plated |
| Scraper material | Polyurethane |
