Specifications
| Maximum Inlet Pressure | 3500 psig / 241 bar / 24,132 kPa - Standard<br>6000 psig / 414 bar / 41,370 kPa- Optional |
| Outlet Pressure Ranges | 25, 50, 100, 250, 500 psig<br>1.7, 3.4, 6.9, 17.2, 34.5 bar<br>172, 345, 690, 1724, 3448 kPa |
| Material | Body: 316 Stainless Steel, Nickel Alloy (Hastelloy®)<br>Seat: Polyimide (Vespel® SP21)<br>Diaphragm and Spring: Cobalt Chrome Nickel Alloy (Elgiloy®), Nickel Alloy (Hastelloy®)<br>Remaining Parts: 316 Stainless Steel, Nickel Alloy (Hastelloy®) |
| Maximum Operating Temperatures | Maximum Media Temperature: 392°F / 200°C<br>Maximum Ambient Temperature: 185 °F / 85 °C for Regulator Body & 149 °F / 65 °C for Electrical Enclosure |
| Minimum Ambient Temperature | -40°F / -40°C |
| Heater | Single heater rated for 100 Watts at 120 VAC and 400 Watts at 240 VAC<br>Heater Temperature Control 270° turn: 122°F to 752°F / 50°C to 400°C<br>Heater Temperature Analog Output: 4-20 mA correlates to a heater thermocouple reading of 122 °F to 752 °F / 50 °C to 400 °C |
| Port size & Type | 1/4" NPTF, Tube Stub |
| Flow Capacity | 0.02 |
| Weight | 6.3 lbs / 2.9 kg |
| Addition Information | For custom modifications or a complete system solution, please contact your local sales office. |
