Specifications
| Pressure Rating | Maximum Inlet Pressure: 500 psig / 34.5 bar <br>Outlet Pressure Ranges: 0-25, 0-50, 0-100, 0-150 psig / 0-1.7, 0-3.4, 0-6.9, 0-10.3 bar |
| Material | Body: 316L Stainless Steel <br>Seat: Teflon®, PEEK-OPTIMA® or PEEK-Classix®<br>O-Ring: Ethylene Propylene<br>Seat Retainer: Nitronic 60<br> |
| Diaphragm, Remaining Parts | 316 Stainless Steel |
| Operating Temperature (media only) | Teflon® Seat: -40°F to 165°F / -40°C to 74°C <br>PEEK-OPTIMA® or PEEK-Classix® Seat: -40°F to 400°F / -40°C to 204°C |
| Port Size & Type | Inlet & Outlet Port Type: Sanitary, Tube <br>Inlet & Outlet Port Size: 1/2, 3/4 |
| Flow Capacity | Cv = 1.8, 1.0 |
| Load Type | Spring |
| Weight (approximately) | 3.5 lbs / 1.6 kg |
| Additional Information | For custom modifications or a complete system solution, please contact your local sales office. |
